Inside NVIDIA’s cuDNN Graph API: Fusion, Autotuning, and Plan Reuse with cuDNN Frontend

This tutorial explores the graph API beneath the framework layer. We represent computations as operation graphs, initially allow cuDNN to select an execution engine, and then manage that selection directly. Each kernel follows a consistent workflow: specify tensor dimensions and strides, connect the operations, complete the five-stage build sequence—validate, build operation graph, create execution plans, check support, and build plans—and execute using a variant pack of pointers.

All experiments run on one Colab GPU, with PyTorch references used to verify fusion correctness and assess performance costs. The examples progress from a fused convolution through engine-config autotuning, FP8-style epilogues, attention, plan serialization, dynamic shapes, and CUDA graph capture.

import os
import sys
import glob
import math
import time
import ctypes
import traceback
import subprocess
RESULTS = {}
def banner(title):
   print("\n" + "=" * 78)
   print(title)
   print("=" * 78)
def section(name):
   def wrap(fn):
       def run(*a, **kw):
           banner(name)
           try:
               out = fn(*a, **kw)
               RESULTS[name] = out if isinstance(out, str) else "ok"
               return out
           except Exception as e:
               RESULTS[name] = f"SKIPPED / FAILED -> {type(e).__name__}: {e}"
               print(f"\n[!] {name} did not complete: {type(e).__name__}: {e}")
               traceback.print_exc(limit=3)
               return None
       return run
   return wrap
banner("0. Install nvidia-cudnn-frontend and locate libcudnn")
subprocess.run(
   [sys.executable, "-m", "pip", "install", "-q", "nvidia-cudnn-frontend"],
   check=True,
)
import torch
assert torch.cuda.is_available(), "No GPU. Runtime -> Change runtime type -> GPU."
torch.backends.cudnn.enabled = True
_ = torch.nn.functional.conv2d(
   torch.randn(1, 1, 8, 8, device="cuda"), torch.randn(1, 1, 3, 3, device="cuda")
)
torch.cuda.synchronize()
try:
   import nvidia.cudnn
   _libdir = os.path.join(os.path.dirname(nvidia.cudnn.__file__), "lib")
   os.environ["CUDNN_PATH"] = os.path.dirname(nvidia.cudnn.__file__)
   os.environ["LD_LIBRARY_PATH"] = _libdir + ":" + os.environ.get("LD_LIBRARY_PATH", "")
   for _so in sorted(glob.glob(os.path.join(_libdir, "libcudnn*.so*"))):
       try:
           ctypes.CDLL(_so, mode=ctypes.RTLD_GLOBAL)
       except OSError:
           pass
except Exception as _e:
   print(f"  (no pip cuDNN package found, relying on system cuDNN: {_e})")
import cudnn
print("  cuDNN frontend imported successfully.")
banner("1. Environment")
DEV = torch.device("cuda")
MAJOR, MINOR = torch.cuda.get_device_capability()
SM = MAJOR * 10 + MINOR
CUDNN_VER = cudnn.backend_version()
print(f"  GPU                 : {torch.cuda.get_device_name(0)}")
print(f"  Compute capability  : sm_{SM}")
print(f"  Torch / CUDA        : {torch.__version__} / {torch.version.cuda}")
print(f"  cuDNN backend       : {CUDNN_VER}")
try:
   print(f"  cuDNN version str   : {cudnn.backend_version_string()}")
except Exception:
   pass
DTYPE = torch.bfloat16 if SM >= 80 else torch.float16
HAS_SDPA = SM >= 80
print(f"  Working dtype       : {DTYPE}")
print(f"  Fused SDPA usable   : {HAS_SDPA}")
HANDLE = cudnn.create_handle()
TORCH2CUDNN = {
   torch.float16: cudnn.data_type.HALF,
   torch.bfloat16: cudnn.data_type.BFLOAT16,
   torch.float32: cudnn.data_type.FLOAT,
   torch.int32: cudnn.data_type.INT32,
   torch.int64: cudnn.data_type.INT64,
   torch.int8: cudnn.data_type.INT8,
   torch.uint8: cudnn.data_type.UINT8,
}
def tensor_of(graph, t, name):
   return graph.tensor(
       name=name,
       dim=list(t.size()),
       stride=list(t.stride()),
       data_type=TORCH2CUDNN[t.dtype],
   )
def scalar_of(graph, name):
   return graph.tensor(
       name=name,
       dim=[1, 1, 1],
       stride=[1, 1, 1],
       data_type=cudnn.data_type.FLOAT,
       is_pass_by_value=True,
   )
def build(graph, heur=None, policy=None):
   heur = heur or [cudnn.heur_mode.A, cudnn.heur_mode.FALLBACK]
   graph.validate()
   graph.build_operation_graph()
   graph.create_execution_plans(heur)
   graph.check_support()
   if policy is None:
       graph.build_plans()
   else:
       graph.build_plans(policy)
   return graph
def workspace_for(graph):
   n = graph.get_workspace_size()
   return torch.empty(max(n, 1), device=DEV, dtype=torch.uint8)
def bench(fn, warmup=10, iters=50):
   for _ in range(warmup):
       fn()
   torch.cuda.synchronize()
   s, e = torch.cuda.Event(True), torch.cuda.Event(True)
   s.record()
   for _ in range(iters):
       fn()
   e.record()
   torch.cuda.synchronize()
   return s.elapsed_time(e) / iters
def tflops(flops, ms):
   return flops / (ms * 1e-3) / 1e12
def report(tag, ms, flops=None):
   extra = f"   ({tflops(flops, ms):7.2f} TFLOP/s)" if flops else ""
   print(f"    {tag:<34s} {ms:8.3f} ms{extra}")

Setup begins with installing nvidia-cudnn-frontend and addressing a frequent first-run obstacle: ensuring that the frontend’s dynamic loader can find libcudnn.so. We first make PyTorch load its bundled cuDNN, then explicitly preload the shared objects. This allows the frontend’s dlopen to resolve to a library already loaded in the process.

Next, we display the GPU’s compute capability, select bfloat16 or float16 to match, and create a cuDNN handle. We also prepare reusable helpers for describing tensors, building graphs, allocating workspace, and benchmarking with events throughout the notebook.

N, C, H, W = 32, 128, 56, 56
K, R, S = 256, 3, 3
PAD, STR, DIL = 1, 1, 1
P = (H + 2 * PAD - DIL * (R - 1) - 1) // STR + 1
Q = (W + 2 * PAD - DIL * (S - 1) - 1) // STR + 1
CONV_FLOPS = 2 * N * K * P * Q * C * R * S
CONV_STATE = {}
@section("2. Fused Conv -> Bias -> ReLU")
def conv_fusion():
   x = torch.randn(N, C, H, W, device=DEV, dtype=DTYPE).to(memory_format=torch.channels_last)
   w = torch.randn(K, C, R, S, device=DEV, dtype=DTYPE).to(memory_format=torch.channels_last)
   b = torch.randn(1, K, 1, 1, device=DEV, dtype=DTYPE)
   y = torch.empty(N, K, P, Q, device=DEV, dtype=DTYPE).to(memory_format=torch.channels_last)
   g = cudnn.pygraph(
       handle=HANDLE,
       name="conv_bias_relu",
       io_data_type=TORCH2CUDNN[DTYPE],
       intermediate_data_type=cudnn.data_type.FLOAT,
       compute_data_type=cudnn.data_type.FLOAT,
   )
   X = tensor_of(g, x, "X")
   Wt = tensor_of(g, w, "W")
   Bt = tensor_of(g, b, "bias")
   conv = g.conv_fprop(
       image=X, weight=Wt,
       padding=[PAD, PAD], stride=[STR, STR], dilation=[DIL, DIL],
       compute_data_type=cudnn.data_type.FLOAT,
   )
   biased = g.bias(input=conv, bias=Bt)
   Y = g.relu(input=biased)
   Y.set_output(True).set_data_type(TORCH2CUDNN[DTYPE])
   Y.set_dim(list(y.size())).set_stride(list(y.stride()))
   t0 = time.perf_counter()
   build(g)
   build_ms = (time.perf_counter() - t0) * 1e3
   ws = workspace_for(g)
   pack = {X: x, Wt: w, Bt: b, Y: y}
   g.execute(pack, ws)
   torch.cuda.synchronize()
   ref = torch.relu(torch.nn.functional.conv2d(x, w, bias=b.flatten(), padding=PAD))
   err = (y.float() - ref.float()).abs().max().item()
   scale = ref.float().abs().max().item()
   print(f"    problem  : N{N} C{C} {H}x{W} -> K{K} {R}x{S}  ({DTYPE})")
   print(f"    build    : {build_ms:.1f} ms   workspace: {ws.numel()/1024:.1f} KiB")
   print(f"    max |err|: {err:.4f}  (ref max {scale:.2f}, rel {err/max(scale,1e-9):.2e})")
   assert err / max(scale, 1e-9) < 5e-2, "numerical mismatch vs PyTorch"
   ms_cudnn = bench(lambda: g.execute(pack, ws))
   ms_torch = bench(lambda: torch.relu(
       torch.nn.functional.conv2d(x, w, bias=b.flatten(), padding=PAD)))
   print()
   report("cuDNN FE (single fused kernel)", ms_cudnn, CONV_FLOPS)
   report("PyTorch (conv+bias, then relu)", ms_torch, CONV_FLOPS)
   print(f"    speedup: {ms_torch/ms_cudnn:.2f}x")
   CONV_STATE.update(graph=g, pack=pack, ws=ws, x=x, w=w, b=b, y=y)
   return f"{ms_cudnn:.3f} ms, {tflops(CONV_FLOPS, ms_cudnn):.1f} TFLOP/s"
conv_fusion()

The opening graph combines convolution, bias addition, and ReLU into one fused kernel. All tensors use channels_last, providing the NHWC strides expected by cuDNN’s tensor-core engines. We also explicitly fix the output dimensions and strides to preserve that layout when writing the result.

For correctness, we compare the output with torch.nn.functional.conv2d. We then measure the fused graph against a PyTorch implementation that launches the convolution and activation as separate kernels.

@section("3. Autotuning: build ALL plans, time each engine config")
def autotune():
   x, w, b, y = CONV_STATE["x"], CONV_STATE["w"], CONV_STATE["b"], CONV_STATE["y"]
   g = cudnn.pygraph(
       handle=HANDLE, name="conv_autotune",
       io_data_type=TORCH2CUDNN[DTYPE],
       intermediate_data_type=cudnn.data_type.FLOAT,
       compute_data_type=cudnn.data_type.FLOAT,
   )
   X = tensor_of(g, x, "X")
   Wt = tensor_of(g, w, "W")
   Bt = tensor_of(g, b, "bias")
   Y = g.relu(input=g.bias(
       input=g.conv_fprop(image=X, weight=Wt, padding=[PAD, PAD],
                          stride=[STR, STR], dilation=[DIL, DIL],
                          compute_data_type=cudnn.data_type.FLOAT),
       bias=Bt))
   Y.set_output(True).set_data_type(TORCH2CUDNN[DTYPE])
   Y.set_dim(list(y.size())).set_stride(list(y.stride()))
   g.validate()
   g.build_operation_graph()
   g.create_execution_plans([cudnn.heur_mode.A, cudnn.heur_mode.B, cudnn.heur_mode.FALLBACK])
   g.check_support()
   g.build_plans(cudnn.build_plan_policy.ALL)
   n_plans = g.get_execution_plan_count()
   print(f"    {n_plans} candidate engine configs survived support checks\n")
   pack = {X: x, Wt: w, Bt: b, Y: y}
   timings = []
   for i in range(n_plans):
       try:
           g.build_plan_at_index(i)
           ws_sz = max(g.get_workspace_size_plan_at_index(i), 1)
           ws = torch.empty(ws_sz, device=DEV, dtype=torch.uint8)
           ms = bench(lambda: g.execute_plan_at_index(pack, ws, i), warmup=3, iters=15)
           timings.append((ms, i, ws_sz))
           print(f"      plan {i:>3d}: {ms:8.3f} ms  "
                 f"{tflops(CONV_FLOPS, ms):7.2f} TFLOP/s  ws={ws_sz/1024:8.1f} KiB")
       except Exception as e:
           print(f"      plan {i:>3d}: unusable ({type(e).__name__})")
   assert timings, "no plan executed"
   timings.sort()
   best_ms, best_i, best_ws = timings[0]
   worst_ms = timings[-1][0]
   print(f"\n    fastest = plan {best_i} @ {best_ms:.3f} ms")
   print(f"    slowest = {worst_ms:.3f} ms  -> {worst_ms/best_ms:.1f}x spread across engines")
   print("    Takeaway: heuristics are good, but for a hot shape you ship the")
   print("    autotuned index (or the serialized plan from section 6).")
   return f"best plan {best_i} @ {best_ms:.3f} ms ({worst_ms/best_ms:.1f}x spread)"
autotune()

Next, we reconstruct the convolution and replace reliance on the default heuristic with a broader search. We request execution plans from heuristic modes A, B, and FALLBACK, compiling every candidate with build_plan_policy.ALL.

We iterate through the plan list, build each configuration, allocate the workspace it requires, and benchmark it using execute_plan_at_index. Throughput and workspace size are reported for every option. The performance gap between the quickest and slowest engines reveals the potential benefit of deploying an autotuned plan index rather than keeping the default selection.

@section("4. Matmul -> scale -> bias -> activation -> AMAX")
def matmul_epilogue():
   Bsz, M, Kd, Nd = 16, 512, 1024, 512
   MM_FLOPS = 2 * Bsz * M * Nd * Kd
   a = torch.randn(Bsz, M, Kd, device=DEV, dtype=DTYPE)
   bm = torch.randn(Bsz, Kd, Nd, device=DEV, dtype=DTYPE)
   bias = torch.randn(1, 1, Nd, device=DEV, dtype=DTYPE)
   out = torch.empty(Bsz, M, Nd, device=DEV, dtype=DTYPE)
   amax = torch.empty(1, 1, 1, device=DEV, dtype=torch.float32)
   alpha_val = 0.125
   alpha = torch.full((1, 1, 1), alpha_val, dtype=torch.float32)
   g = cudnn.pygraph(
       handle=HANDLE, name="matmul_epilogue",
       io_data_type=TORCH2CUDNN[DTYPE],
       intermediate_data_type=cudnn.data_type.FLOAT,
       compute_data_type=cudnn.data_type.FLOAT,
   )
   A = tensor_of(g, a, "A")
   Bt = tensor_of(g, bm, "B")
   BIAS = tensor_of(g, bias, "bias")
   ALPHA = scalar_of(g, "alpha")
   acc = g.matmul(A=A, B=Bt, compute_data_type=cudnn.data_type.FLOAT)
   scaled = g.mul(a=acc, b=ALPHA)
   biased = g.bias(input=scaled, bias=BIAS)
   act_name = "relu"
   if hasattr(g, "gelu"):
       try:
           act = g.gelu(input=biased)
           act_name = "gelu"
       except Exception:
           act = g.relu(input=biased)
   else:
       act = g.relu(input=biased)
   print(f"    activation used: {act_name}")
   OUT = act
   OUT.set_output(True).set_data_type(TORCH2CUDNN[DTYPE])
   have_amax = True
   try:
       AMAX = g.reduction(input=act, mode=cudnn.reduction_mode.AMAX,
                          compute_data_type=cudnn.data_type.FLOAT)
       AMAX.set_output(True).set_data_type(cudnn.data_type.FLOAT)
       AMAX.set_dim([1, 1, 1]).set_stride([1, 1, 1])
   except Exception as e:
       have_amax = False
       print(f"    (AMAX reduction unavailable here: {e})")
   build(g)
   ws = workspace_for(g)
   pack = {A: a, Bt: bm, BIAS: bias, ALPHA: alpha, OUT: out}
   if have_amax:
       pack[AMAX] = amax
   g.execute(pack, ws)
   torch.cuda.synchronize()
   ref = torch.matmul(a.float(), bm.float()) * alpha_val + bias.float()
   ref = torch.nn.functional.gelu(ref) if act_name == "gelu" else torch.relu(ref)
   rel = ((out.float() - ref).abs().max() / ref.abs().max()).item()
   print(f"    shape    : ({Bsz},{M},{Kd}) x ({Bsz},{Kd},{Nd})")
   print(f"    rel err  : {rel:.2e}")
   if have_amax:
       print(f"    fused AMAX {amax.item():.4f} vs torch {ref.abs().max().item():.4f}")
   ms = bench(lambda: g.execute(pack, ws))
   def torch_ref():
       r = torch.baddbmm(bias.expand(Bsz, M, Nd), a, bm, beta=1.0, alpha=alpha_val)
       r = torch.nn.functional.gelu(r) if act_name == "gelu" else torch.relu(r)
       return r.abs().amax()
   ms_t = bench(torch_ref)
   print()
   report("cuDNN FE (one fused kernel)", ms, MM_FLOPS)
   report("PyTorch (bmm + act + amax)", ms_t, MM_FLOPS)
   print(f"    speedup: {ms_t/ms:.2f}x  -- the win is the epilogue traffic, not the GEMM")
   return f"{ms:.3f} ms, {tflops(MM_FLOPS, ms):.1f} TFLOP/s, {ms_t/ms:.2f}x vs torch"
matmul_epilogue()

A batched matmul provides the foundation for the next graph, which attaches a complete epilogue: alpha scaling through a pass-by-value host scalar, bias addition, an activation, and an AMAX reduction of the result. Performing AMAX within the same kernel follows a pattern used in FP8 training: it gathers the scale factor needed for the next quantization step without reading the output in a separate pass.

We benchmark this graph against a PyTorch sequence of baddbmm, activation, and amax. The comparison highlights that the gain comes from removing epilogue memory traffic, not from accelerating the GEMM itself.

@section("5. SDPA (Flash Attention) with causal masking")
def sdpa_demo():
   if not HAS_SDPA:
       raise RuntimeError(f"fused SDPA needs SM80+ (Ampere), this GPU is sm_{SM}")
   b, h, s, d = 4, 16, 1024, 64
   scale = 1.0 / math.sqrt(d)
   SDPA_FLOPS = 4 * b * h * s * s * d * 0.5
   q = torch.randn(b, h, s, d, device=DEV, dtype=DTYPE)
   k = torch.randn(b, h, s, d, device=DEV, dtype=DTYPE)
   v = torch.randn(b, h, s, d, device=DEV, dtype=DTYPE)
   o = torch.empty(b, h, s, d, device=DEV, dtype=DTYPE)
   g = cudnn.pygraph(
       handle=HANDLE, name="sdpa",
       io_data_type=TORCH2CUDNN[DTYPE],
       intermediate_data_type=cudnn.data_type.FLOAT,
       compute_data_type=cudnn.data_type.FLOAT,
   )
   Q, Kt, V = tensor_of(g, q, "Q"), tensor_of(g, k, "K"), tensor_of(g, v, "V")
   causal = True
   try:
       O, _stats = g.sdpa(name="sdpa", q=Q, k=Kt, v=V,
                          is_inference=True, attn_scale=scale, use_causal_mask=True)
   except TypeError:
       try:
           O, _stats = g.sdpa(name="sdpa", q=Q, k=Kt, v=V,
                              is_inference=True, attn_scale=scale,
                              diagonal_alignment=cudnn.diagonal_alignment.TOP_LEFT,
                              right_bound=0)
       except Exception:
           causal = False
           O, _stats = g.sdpa(name="sdpa", q=Q, k=Kt, v=V,
                              is_inference=True, attn_scale=scale)
   print(f"    causal masking: {causal}")
   O.set_output(True).set_data_type(TORCH2CUDNN[DTYPE])
   O.set_dim(list(o.size())).set_stride(list(o.stride()))
   build(g)
   ws = workspace_for(g)
   pack = {Q: q, Kt: k, V: v, O: o}
   g.execute(pack, ws)
   torch.cuda.synchronize()
   ref = torch.nn.functional.scaled_dot_product_attention(q, k, v, is_causal=causal, scale=scale)
   rel = ((o.float() - ref.float()).abs().max() / ref.float().abs().max()).item()
   print(f"    shape   : b{b} h{h} s{s} d{d}   workspace {ws.numel()/1024:.1f} KiB")
   print(f"    rel err : {rel:.2e}")
   ms = bench(lambda: g.execute(pack, ws))
   ms_t = bench(lambda: torch.nn.functional.scaled_dot_product_attention(
       q, k, v, is_causal=causal, scale=scale))
   print()
   report("cuDNN FE SDPA", ms, SDPA_FLOPS)
   report("torch SDPA (backend's choice)", ms_t, SDPA_FLOPS)
   print("    Note: torch may already be dispatching to cuDNN or FlashAttention,")
   print("    so parity here is the expected, healthy outcome.")
   return f"{ms:.3f} ms, {tflops(SDPA_FLOPS, ms):.1f} TFLOP/s"
sdpa_demo()
@section("6. Serialize a built graph, reload it, execute by UID")
def serialization():
   Bsz, M, Kd, Nd = 8, 256, 512, 256
   a = torch.randn(Bsz, M, Kd, device=DEV, dtype=DTYPE)
   bm = torch.randn(Bsz, Kd, Nd, device=DEV, dtype=DTYPE)
   out = torch.empty(Bsz, M, Nd, device=DEV, dtype=DTYPE)
   UID_A, UID_B, UID_C = 1, 2, 3
   g = cudnn.pygraph(
       handle=HANDLE, name="serializable_mm",
       io_data_type=TORCH2CUDNN[DTYPE],
       intermediate_data_type=cudnn.data_type.FLOAT,
       compute_data_type=cudnn.data_type.FLOAT,
   )
   A = tensor_of(g, a, "A").set_uid(UID_A)
   Bt = tensor_of(g, bm, "B").set_uid(UID_B)
   C = g.matmul(A=A, B=Bt, compute_data_type=cudnn.data_type.FLOAT)
   C.set_output(True).set_data_type(TORCH2CUDNN[DTYPE]).set_uid(UID_C)
   t0 = time.perf_counter()
   build(g)
   cold_ms = (time.perf_counter() - t0) * 1e3
   blob = g.serialize()
   print(f"    cold build      : {cold_ms:.1f} ms")
   print(f"    serialized plan : {len(blob)} bytes (cache this to disk / ship it)")
   t0 = time.perf_counter()
   g2 = cudnn.pygraph()
   try:
       g2.deserialize(HANDLE, blob)
   except TypeError:
       g2.deserialize(blob)
   warm_ms = (time.perf_counter() - t0) * 1e3
   print(f"    deserialize     : {warm_ms:.1f} ms  -> {cold_ms/max(warm_ms,1e-6):.1f}x faster startup")
   ws = torch.empty(max(g2.get_workspace_size(), 1), device=DEV, dtype=torch.uint8)
   g2.execute({UID_A: a, UID_B: bm, UID_C: out}, ws, handle=HANDLE)
   torch.cuda.synchronize()
   ref = torch.bmm(a.float(), bm.float())
   rel = ((out.float() - ref).abs().max() / ref.abs().max()).item()
   print(f"    rel err after reload: {rel:.2e}")
   return f"{len(blob)} B blob, reload {cold_ms/max(warm_ms,1e-6):.1f}x faster than rebuild"
serialization()

We then construct fused scaled dot-product attention with causal masking and validate it against torch.nn.functional.scaled_dot_product_attention. An SM80 check gates this entire section, since the fused kernels require Ampere or a newer architecture. To accommodate changes across the frontend’s 1.x releases, the causal argument includes fallbacks for the transition from use_causal_mask to diagonal_alignment and bound arguments.

Afterward, we serialize a built matmul graph into bytes, restore it in a new graph object, and run it using integer UIDs. Reloading the built graph avoids compilation costs entirely at process startup.

@section("7. Dynamic shapes with a shared kernel cache")
def dynamic_shapes():
   kc = cudnn.create_kernel_cache()
   def make(n):
       x = torch.randn(n, 64, 32, 32, device=DEV, dtype=DTYPE).to(memory_format=torch.channels_last)
       w = torch.randn(64, 64, 3, 3, device=DEV, dtype=DTYPE).to(memory_format=torch.channels_last)
       y = torch.empty(n, 64, 32, 32, device=DEV, dtype=DTYPE).to(memory_format=torch.channels_last)
       g = cudnn.pygraph(
           handle=HANDLE, name=f"dyn_{n}",
           io_data_type=TORCH2CUDNN[DTYPE],
           intermediate_data_type=cudnn.data_type.FLOAT,
           compute_data_type=cudnn.data_type.FLOAT,
           kernel_cache=kc,
           is_dynamic_shape_enabled=True,
       )
       X, Wt = tensor_of(g, x, "X"), tensor_of(g, w, "W")
       Y = g.conv_fprop(image=X, weight=Wt, padding=[1, 1], stride=[1, 1],
                        dilation=[1, 1], compute_data_type=cudnn.data_type.FLOAT)
       Y.set_output(True).set_data_type(TORCH2CUDNN[DTYPE])
       Y.set_dim(list(y.size())).set_stride(list(y.stride()))
       t0 = time.perf_counter()
       build(g)
       ms = (time.perf_counter() - t0) * 1e3
       ws = workspace_for(g)
       g.execute({X: x, Wt: w, Y: y}, ws)
       torch.cuda.synchronize()
       return ms
   times = [(n, make(n)) for n in (8, 16, 24, 32)]
   for n, ms in times:
       print(f"      batch {n:>3d}: build {ms:7.1f} ms")
   first, rest = times[0][1], [m for _, m in times[1:]]
   print(f"\n    first shape {first:.1f} ms, later shapes avg {sum(rest)/len(rest):.1f} ms")
   print("    The cache lets shape-variant graphs reuse an already-JIT'd kernel,")
   print("    which is what keeps variable batch/seqlen serving out of rebuild hell.")
   return f"first {first:.0f} ms vs subsequent {sum(rest)/len(rest):.0f} ms"
dynamic_shapes()
@section("8. CUDA Graph capture around a cuDNN execution plan")
def cuda_graph_capture():
   if not CONV_STATE:
       raise RuntimeError("section 2 did not run, nothing to capture")
   g, pack, ws = CONV_STATE["graph"], CONV_STATE["pack"], CONV_STATE["ws"]
   eager_ms = bench(lambda: g.execute(pack, ws))
   side = torch.cuda.Stream()
   side.wait_stream(torch.cuda.current_stream())
   with torch.cuda.stream(side):
       cudnn.set_stream(handle=HANDLE, stream=side.cuda_stream)
       for _ in range(3):
           g.execute(pack, ws, handle=HANDLE)
   torch.cuda.current_stream().wait_stream(side)
   torch.cuda.synchronize()
   cg = torch.cuda.CUDAGraph()
   with torch.cuda.graph(cg):
       cudnn.set_stream(handle=HANDLE, stream=torch.cuda.current_stream().cuda_stream)
       g.execute(pack, ws, handle=HANDLE)
   cudnn.set_stream(handle=HANDLE, stream=torch.cuda.current_stream().cuda_stream)
   replay_ms = bench(lambda: cg.replay())
   report("plain execute()", eager_ms)
   report("cuda graph replay()", replay_ms)
   print(f"    launch overhead removed: {(eager_ms-replay_ms)*1e3:.1f} us/iter")
   print("    Pointers are frozen at capture time -- reuse the same buffers and")
   print("    copy new data into them, or re-capture.")
   return f"{eager_ms:.3f} -> {replay_ms:.3f} ms via replay"
cuda_graph_capture()
banner("SUMMARY")
for name, res in RESULTS.items():
   print(f"  {name:<58s} {res}")
print("""
Where to go next
 - samples/python in the repo: FP8/MXFP8 attention, paged KV cache, MoE grouped GEMM
 - python/cudnn/: the open-sourced CuTe DSL kernels (SDPA, grouped GEMM + SwiGLU,
   block-sparse and native sparse attention) you can read and modify
 - debugging: CUDNN_FRONTEND_LOG_INFO=1 and CUDNN_FRONTEND_LOG_FILE=stdout
   (use level 10 during CUDA graph capture -- level 1 dumps tensors and is not
   capture-safe)
""")

The final experiments address two production considerations. First, four graphs with different batch sizes share a single kernel cache. By timing each build, we can observe subsequent shapes reusing a compiled kernel rather than incurring another JIT compilation cost.

Second, we place the convolution plan inside a CUDA graph. We assign the capture stream to the cuDNN handle so that its work is recorded in the graph, then measure how much per-iteration launch overhead disappears during replay.

Although the implementation is compact, it covers convolution, matmul, and attention kernels, all defined as graphs instead of individual library calls. That lower-level representation gives us control over which operations fuse into one kernel. Bias additions, activations, and AMAX reductions incorporated into epilogues therefore avoid writing intermediate results to memory.

It also lets us select execution engines directly. Benchmarking every candidate configuration quantifies the value of that choice instead of leaving it to a heuristic. Serialized plans and a kernel cache shared across shapes move compilation out of the hot path, while CUDA graph capture addresses repeated launch overhead.

Correctness checks against PyTorch are just as important as performance measurements. Cases where our implementation only matched PyTorch often reflected PyTorch already using cuDNN internally. Together, these results show where the graph API offers the most value: fusions unavailable at the framework level, frequently used shapes that warrant autotuning, and small kernels whose runtime is dominated by startup and launch costs.

This tutorial explores the graph API beneath the framework layer. We represent computations as operation graphs, initially allow cuDNN to select an execution engine, and then manage that selection directly. Each kernel follows a consistent workflow: specify tensor dimensions and strides, connect the operations, complete the five-stage build sequence—validate, build operation graph, create execution plans, check support, and build plans—and execute using a variant pack of pointers.

All experiments run on one Colab GPU, with PyTorch references used to verify fusion correctness and assess performance costs. The examples progress from a fused convolution through engine-config autotuning, FP8-style epilogues, attention, plan serialization, dynamic shapes, and CUDA graph capture.

import os
import sys
import glob
import math
import time
import ctypes
import traceback
import subprocess
RESULTS = {}
def banner(title):
   print("\n" + "=" * 78)
   print(title)
   print("=" * 78)
def section(name):
   def wrap(fn):
       def run(*a, **kw):
           banner(name)
           try:
               out = fn(*a, **kw)
               RESULTS[name] = out if isinstance(out, str) else "ok"
               return out
           except Exception as e:
               RESULTS[name] = f"SKIPPED / FAILED -> {type(e).__name__}: {e}"
               print(f"\n[!] {name} did not complete: {type(e).__name__}: {e}")
               traceback.print_exc(limit=3)
               return None
       return run
   return wrap
banner("0. Install nvidia-cudnn-frontend and locate libcudnn")
subprocess.run(
   [sys.executable, "-m", "pip", "install", "-q", "nvidia-cudnn-frontend"],
   check=True,
)
import torch
assert torch.cuda.is_available(), "No GPU. Runtime -> Change runtime type -> GPU."
torch.backends.cudnn.enabled = True
_ = torch.nn.functional.conv2d(
   torch.randn(1, 1, 8, 8, device="cuda"), torch.randn(1, 1, 3, 3, device="cuda")
)
torch.cuda.synchronize()
try:
   import nvidia.cudnn
   _libdir = os.path.join(os.path.dirname(nvidia.cudnn.__file__), "lib")
   os.environ["CUDNN_PATH"] = os.path.dirname(nvidia.cudnn.__file__)
   os.environ["LD_LIBRARY_PATH"] = _libdir + ":" + os.environ.get("LD_LIBRARY_PATH", "")
   for _so in sorted(glob.glob(os.path.join(_libdir, "libcudnn*.so*"))):
       try:
           ctypes.CDLL(_so, mode=ctypes.RTLD_GLOBAL)
       except OSError:
           pass
except Exception as _e:
   print(f"  (no pip cuDNN package found, relying on system cuDNN: {_e})")
import cudnn
print("  cuDNN frontend imported successfully.")
banner("1. Environment")
DEV = torch.device("cuda")
MAJOR, MINOR = torch.cuda.get_device_capability()
SM = MAJOR * 10 + MINOR
CUDNN_VER = cudnn.backend_version()
print(f"  GPU                 : {torch.cuda.get_device_name(0)}")
print(f"  Compute capability  : sm_{SM}")
print(f"  Torch / CUDA        : {torch.__version__} / {torch.version.cuda}")
print(f"  cuDNN backend       : {CUDNN_VER}")
try:
   print(f"  cuDNN version str   : {cudnn.backend_version_string()}")
except Exception:
   pass
DTYPE = torch.bfloat16 if SM >= 80 else torch.float16
HAS_SDPA = SM >= 80
print(f"  Working dtype       : {DTYPE}")
print(f"  Fused SDPA usable   : {HAS_SDPA}")
HANDLE = cudnn.create_handle()
TORCH2CUDNN = {
   torch.float16: cudnn.data_type.HALF,
   torch.bfloat16: cudnn.data_type.BFLOAT16,
   torch.float32: cudnn.data_type.FLOAT,
   torch.int32: cudnn.data_type.INT32,
   torch.int64: cudnn.data_type.INT64,
   torch.int8: cudnn.data_type.INT8,
   torch.uint8: cudnn.data_type.UINT8,
}
def tensor_of(graph, t, name):
   return graph.tensor(
       name=name,
       dim=list(t.size()),
       stride=list(t.stride()),
       data_type=TORCH2CUDNN[t.dtype],
   )
def scalar_of(graph, name):
   return graph.tensor(
       name=name,
       dim=[1, 1, 1],
       stride=[1, 1, 1],
       data_type=cudnn.data_type.FLOAT,
       is_pass_by_value=True,
   )
def build(graph, heur=None, policy=None):
   heur = heur or [cudnn.heur_mode.A, cudnn.heur_mode.FALLBACK]
   graph.validate()
   graph.build_operation_graph()
   graph.create_execution_plans(heur)
   graph.check_support()
   if policy is None:
       graph.build_plans()
   else:
       graph.build_plans(policy)
   return graph
def workspace_for(graph):
   n = graph.get_workspace_size()
   return torch.empty(max(n, 1), device=DEV, dtype=torch.uint8)
def bench(fn, warmup=10, iters=50):
   for _ in range(warmup):
       fn()
   torch.cuda.synchronize()
   s, e = torch.cuda.Event(True), torch.cuda.Event(True)
   s.record()
   for _ in range(iters):
       fn()
   e.record()
   torch.cuda.synchronize()
   return s.elapsed_time(e) / iters
def tflops(flops, ms):
   return flops / (ms * 1e-3) / 1e12
def report(tag, ms, flops=None):
   extra = f"   ({tflops(flops, ms):7.2f} TFLOP/s)" if flops else ""
   print(f"    {tag:<34s} {ms:8.3f} ms{extra}")

Setup begins with installing nvidia-cudnn-frontend and addressing a frequent first-run obstacle: ensuring that the frontend’s dynamic loader can find libcudnn.so. We first make PyTorch load its bundled cuDNN, then explicitly preload the shared objects. This allows the frontend’s dlopen to resolve to a library already loaded in the process.

Next, we display the GPU’s compute capability, select bfloat16 or float16 to match, and create a cuDNN handle. We also prepare reusable helpers for describing tensors, building graphs, allocating workspace, and benchmarking with events throughout the notebook.

N, C, H, W = 32, 128, 56, 56
K, R, S = 256, 3, 3
PAD, STR, DIL = 1, 1, 1
P = (H + 2 * PAD - DIL * (R - 1) - 1) // STR + 1
Q = (W + 2 * PAD - DIL * (S - 1) - 1) // STR + 1
CONV_FLOPS = 2 * N * K * P * Q * C * R * S
CONV_STATE = {}
@section("2. Fused Conv -> Bias -> ReLU")
def conv_fusion():
   x = torch.randn(N, C, H, W, device=DEV, dtype=DTYPE).to(memory_format=torch.channels_last)
   w = torch.randn(K, C, R, S, device=DEV, dtype=DTYPE).to(memory_format=torch.channels_last)
   b = torch.randn(1, K, 1, 1, device=DEV, dtype=DTYPE)
   y = torch.empty(N, K, P, Q, device=DEV, dtype=DTYPE).to(memory_format=torch.channels_last)
   g = cudnn.pygraph(
       handle=HANDLE,
       name="conv_bias_relu",
       io_data_type=TORCH2CUDNN[DTYPE],
       intermediate_data_type=cudnn.data_type.FLOAT,
       compute_data_type=cudnn.data_type.FLOAT,
   )
   X = tensor_of(g, x, "X")
   Wt = tensor_of(g, w, "W")
   Bt = tensor_of(g, b, "bias")
   conv = g.conv_fprop(
       image=X, weight=Wt,
       padding=[PAD, PAD], stride=[STR, STR], dilation=[DIL, DIL],
       compute_data_type=cudnn.data_type.FLOAT,
   )
   biased = g.bias(input=conv, bias=Bt)
   Y = g.relu(input=biased)
   Y.set_output(True).set_data_type(TORCH2CUDNN[DTYPE])
   Y.set_dim(list(y.size())).set_stride(list(y.stride()))
   t0 = time.perf_counter()
   build(g)
   build_ms = (time.perf_counter() - t0) * 1e3
   ws = workspace_for(g)
   pack = {X: x, Wt: w, Bt: b, Y: y}
   g.execute(pack, ws)
   torch.cuda.synchronize()
   ref = torch.relu(torch.nn.functional.conv2d(x, w, bias=b.flatten(), padding=PAD))
   err = (y.float() - ref.float()).abs().max().item()
   scale = ref.float().abs().max().item()
   print(f"    problem  : N{N} C{C} {H}x{W} -> K{K} {R}x{S}  ({DTYPE})")
   print(f"    build    : {build_ms:.1f} ms   workspace: {ws.numel()/1024:.1f} KiB")
   print(f"    max |err|: {err:.4f}  (ref max {scale:.2f}, rel {err/max(scale,1e-9):.2e})")
   assert err / max(scale, 1e-9) < 5e-2, "numerical mismatch vs PyTorch"
   ms_cudnn = bench(lambda: g.execute(pack, ws))
   ms_torch = bench(lambda: torch.relu(
       torch.nn.functional.conv2d(x, w, bias=b.flatten(), padding=PAD)))
   print()
   report("cuDNN FE (single fused kernel)", ms_cudnn, CONV_FLOPS)
   report("PyTorch (conv+bias, then relu)", ms_torch, CONV_FLOPS)
   print(f"    speedup: {ms_torch/ms_cudnn:.2f}x")
   CONV_STATE.update(graph=g, pack=pack, ws=ws, x=x, w=w, b=b, y=y)
   return f"{ms_cudnn:.3f} ms, {tflops(CONV_FLOPS, ms_cudnn):.1f} TFLOP/s"
conv_fusion()

The opening graph combines convolution, bias addition, and ReLU into one fused kernel. All tensors use channels_last, providing the NHWC strides expected by cuDNN’s tensor-core engines. We also explicitly fix the output dimensions and strides to preserve that layout when writing the result.

For correctness, we compare the output with torch.nn.functional.conv2d. We then measure the fused graph against a PyTorch implementation that launches the convolution and activation as separate kernels.

@section("3. Autotuning: build ALL plans, time each engine config")
def autotune():
   x, w, b, y = CONV_STATE["x"], CONV_STATE["w"], CONV_STATE["b"], CONV_STATE["y"]
   g = cudnn.pygraph(
       handle=HANDLE, name="conv_autotune",
       io_data_type=TORCH2CUDNN[DTYPE],
       intermediate_data_type=cudnn.data_type.FLOAT,
       compute_data_type=cudnn.data_type.FLOAT,
   )
   X = tensor_of(g, x, "X")
   Wt = tensor_of(g, w, "W")
   Bt = tensor_of(g, b, "bias")
   Y = g.relu(input=g.bias(
       input=g.conv_fprop(image=X, weight=Wt, padding=[PAD, PAD],
                          stride=[STR, STR], dilation=[DIL, DIL],
                          compute_data_type=cudnn.data_type.FLOAT),
       bias=Bt))
   Y.set_output(True).set_data_type(TORCH2CUDNN[DTYPE])
   Y.set_dim(list(y.size())).set_stride(list(y.stride()))
   g.validate()
   g.build_operation_graph()
   g.create_execution_plans([cudnn.heur_mode.A, cudnn.heur_mode.B, cudnn.heur_mode.FALLBACK])
   g.check_support()
   g.build_plans(cudnn.build_plan_policy.ALL)
   n_plans = g.get_execution_plan_count()
   print(f"    {n_plans} candidate engine configs survived support checks\n")
   pack = {X: x, Wt: w, Bt: b, Y: y}
   timings = []
   for i in range(n_plans):
       try:
           g.build_plan_at_index(i)
           ws_sz = max(g.get_workspace_size_plan_at_index(i), 1)
           ws = torch.empty(ws_sz, device=DEV, dtype=torch.uint8)
           ms = bench(lambda: g.execute_plan_at_index(pack, ws, i), warmup=3, iters=15)
           timings.append((ms, i, ws_sz))
           print(f"      plan {i:>3d}: {ms:8.3f} ms  "
                 f"{tflops(CONV_FLOPS, ms):7.2f} TFLOP/s  ws={ws_sz/1024:8.1f} KiB")
       except Exception as e:
           print(f"      plan {i:>3d}: unusable ({type(e).__name__})")
   assert timings, "no plan executed"
   timings.sort()
   best_ms, best_i, best_ws = timings[0]
   worst_ms = timings[-1][0]
   print(f"\n    fastest = plan {best_i} @ {best_ms:.3f} ms")
   print(f"    slowest = {worst_ms:.3f} ms  -> {worst_ms/best_ms:.1f}x spread across engines")
   print("    Takeaway: heuristics are good, but for a hot shape you ship the")
   print("    autotuned index (or the serialized plan from section 6).")
   return f"best plan {best_i} @ {best_ms:.3f} ms ({worst_ms/best_ms:.1f}x spread)"
autotune()

Next, we reconstruct the convolution and replace reliance on the default heuristic with a broader search. We request execution plans from heuristic modes A, B, and FALLBACK, compiling every candidate with build_plan_policy.ALL.

We iterate through the plan list, build each configuration, allocate the workspace it requires, and benchmark it using execute_plan_at_index. Throughput and workspace size are reported for every option. The performance gap between the quickest and slowest engines reveals the potential benefit of deploying an autotuned plan index rather than keeping the default selection.

@section("4. Matmul -> scale -> bias -> activation -> AMAX")
def matmul_epilogue():
   Bsz, M, Kd, Nd = 16, 512, 1024, 512
   MM_FLOPS = 2 * Bsz * M * Nd * Kd
   a = torch.randn(Bsz, M, Kd, device=DEV, dtype=DTYPE)
   bm = torch.randn(Bsz, Kd, Nd, device=DEV, dtype=DTYPE)
   bias = torch.randn(1, 1, Nd, device=DEV, dtype=DTYPE)
   out = torch.empty(Bsz, M, Nd, device=DEV, dtype=DTYPE)
   amax = torch.empty(1, 1, 1, device=DEV, dtype=torch.float32)
   alpha_val = 0.125
   alpha = torch.full((1, 1, 1), alpha_val, dtype=torch.float32)
   g = cudnn.pygraph(
       handle=HANDLE, name="matmul_epilogue",
       io_data_type=TORCH2CUDNN[DTYPE],
       intermediate_data_type=cudnn.data_type.FLOAT,
       compute_data_type=cudnn.data_type.FLOAT,
   )
   A = tensor_of(g, a, "A")
   Bt = tensor_of(g, bm, "B")
   BIAS = tensor_of(g, bias, "bias")
   ALPHA = scalar_of(g, "alpha")
   acc = g.matmul(A=A, B=Bt, compute_data_type=cudnn.data_type.FLOAT)
   scaled = g.mul(a=acc, b=ALPHA)
   biased = g.bias(input=scaled, bias=BIAS)
   act_name = "relu"
   if hasattr(g, "gelu"):
       try:
           act = g.gelu(input=biased)
           act_name = "gelu"
       except Exception:
           act = g.relu(input=biased)
   else:
       act = g.relu(input=biased)
   print(f"    activation used: {act_name}")
   OUT = act
   OUT.set_output(True).set_data_type(TORCH2CUDNN[DTYPE])
   have_amax = True
   try:
       AMAX = g.reduction(input=act, mode=cudnn.reduction_mode.AMAX,
                          compute_data_type=cudnn.data_type.FLOAT)
       AMAX.set_output(True).set_data_type(cudnn.data_type.FLOAT)
       AMAX.set_dim([1, 1, 1]).set_stride([1, 1, 1])
   except Exception as e:
       have_amax = False
       print(f"    (AMAX reduction unavailable here: {e})")
   build(g)
   ws = workspace_for(g)
   pack = {A: a, Bt: bm, BIAS: bias, ALPHA: alpha, OUT: out}
   if have_amax:
       pack[AMAX] = amax
   g.execute(pack, ws)
   torch.cuda.synchronize()
   ref = torch.matmul(a.float(), bm.float()) * alpha_val + bias.float()
   ref = torch.nn.functional.gelu(ref) if act_name == "gelu" else torch.relu(ref)
   rel = ((out.float() - ref).abs().max() / ref.abs().max()).item()
   print(f"    shape    : ({Bsz},{M},{Kd}) x ({Bsz},{Kd},{Nd})")
   print(f"    rel err  : {rel:.2e}")
   if have_amax:
       print(f"    fused AMAX {amax.item():.4f} vs torch {ref.abs().max().item():.4f}")
   ms = bench(lambda: g.execute(pack, ws))
   def torch_ref():
       r = torch.baddbmm(bias.expand(Bsz, M, Nd), a, bm, beta=1.0, alpha=alpha_val)
       r = torch.nn.functional.gelu(r) if act_name == "gelu" else torch.relu(r)
       return r.abs().amax()
   ms_t = bench(torch_ref)
   print()
   report("cuDNN FE (one fused kernel)", ms, MM_FLOPS)
   report("PyTorch (bmm + act + amax)", ms_t, MM_FLOPS)
   print(f"    speedup: {ms_t/ms:.2f}x  -- the win is the epilogue traffic, not the GEMM")
   return f"{ms:.3f} ms, {tflops(MM_FLOPS, ms):.1f} TFLOP/s, {ms_t/ms:.2f}x vs torch"
matmul_epilogue()

A batched matmul provides the foundation for the next graph, which attaches a complete epilogue: alpha scaling through a pass-by-value host scalar, bias addition, an activation, and an AMAX reduction of the result. Performing AMAX within the same kernel follows a pattern used in FP8 training: it gathers the scale factor needed for the next quantization step without reading the output in a separate pass.

We benchmark this graph against a PyTorch sequence of baddbmm, activation, and amax. The comparison highlights that the gain comes from removing epilogue memory traffic, not from accelerating the GEMM itself.

@section("5. SDPA (Flash Attention) with causal masking")
def sdpa_demo():
   if not HAS_SDPA:
       raise RuntimeError(f"fused SDPA needs SM80+ (Ampere), this GPU is sm_{SM}")
   b, h, s, d = 4, 16, 1024, 64
   scale = 1.0 / math.sqrt(d)
   SDPA_FLOPS = 4 * b * h * s * s * d * 0.5
   q = torch.randn(b, h, s, d, device=DEV, dtype=DTYPE)
   k = torch.randn(b, h, s, d, device=DEV, dtype=DTYPE)
   v = torch.randn(b, h, s, d, device=DEV, dtype=DTYPE)
   o = torch.empty(b, h, s, d, device=DEV, dtype=DTYPE)
   g = cudnn.pygraph(
       handle=HANDLE, name="sdpa",
       io_data_type=TORCH2CUDNN[DTYPE],
       intermediate_data_type=cudnn.data_type.FLOAT,
       compute_data_type=cudnn.data_type.FLOAT,
   )
   Q, Kt, V = tensor_of(g, q, "Q"), tensor_of(g, k, "K"), tensor_of(g, v, "V")
   causal = True
   try:
       O, _stats = g.sdpa(name="sdpa", q=Q, k=Kt, v=V,
                          is_inference=True, attn_scale=scale, use_causal_mask=True)
   except TypeError:
       try:
           O, _stats = g.sdpa(name="sdpa", q=Q, k=Kt, v=V,
                              is_inference=True, attn_scale=scale,
                              diagonal_alignment=cudnn.diagonal_alignment.TOP_LEFT,
                              right_bound=0)
       except Exception:
           causal = False
           O, _stats = g.sdpa(name="sdpa", q=Q, k=Kt, v=V,
                              is_inference=True, attn_scale=scale)
   print(f"    causal masking: {causal}")
   O.set_output(True).set_data_type(TORCH2CUDNN[DTYPE])
   O.set_dim(list(o.size())).set_stride(list(o.stride()))
   build(g)
   ws = workspace_for(g)
   pack = {Q: q, Kt: k, V: v, O: o}
   g.execute(pack, ws)
   torch.cuda.synchronize()
   ref = torch.nn.functional.scaled_dot_product_attention(q, k, v, is_causal=causal, scale=scale)
   rel = ((o.float() - ref.float()).abs().max() / ref.float().abs().max()).item()
   print(f"    shape   : b{b} h{h} s{s} d{d}   workspace {ws.numel()/1024:.1f} KiB")
   print(f"    rel err : {rel:.2e}")
   ms = bench(lambda: g.execute(pack, ws))
   ms_t = bench(lambda: torch.nn.functional.scaled_dot_product_attention(
       q, k, v, is_causal=causal, scale=scale))
   print()
   report("cuDNN FE SDPA", ms, SDPA_FLOPS)
   report("torch SDPA (backend's choice)", ms_t, SDPA_FLOPS)
   print("    Note: torch may already be dispatching to cuDNN or FlashAttention,")
   print("    so parity here is the expected, healthy outcome.")
   return f"{ms:.3f} ms, {tflops(SDPA_FLOPS, ms):.1f} TFLOP/s"
sdpa_demo()
@section("6. Serialize a built graph, reload it, execute by UID")
def serialization():
   Bsz, M, Kd, Nd = 8, 256, 512, 256
   a = torch.randn(Bsz, M, Kd, device=DEV, dtype=DTYPE)
   bm = torch.randn(Bsz, Kd, Nd, device=DEV, dtype=DTYPE)
   out = torch.empty(Bsz, M, Nd, device=DEV, dtype=DTYPE)
   UID_A, UID_B, UID_C = 1, 2, 3
   g = cudnn.pygraph(
       handle=HANDLE, name="serializable_mm",
       io_data_type=TORCH2CUDNN[DTYPE],
       intermediate_data_type=cudnn.data_type.FLOAT,
       compute_data_type=cudnn.data_type.FLOAT,
   )
   A = tensor_of(g, a, "A").set_uid(UID_A)
   Bt = tensor_of(g, bm, "B").set_uid(UID_B)
   C = g.matmul(A=A, B=Bt, compute_data_type=cudnn.data_type.FLOAT)
   C.set_output(True).set_data_type(TORCH2CUDNN[DTYPE]).set_uid(UID_C)
   t0 = time.perf_counter()
   build(g)
   cold_ms = (time.perf_counter() - t0) * 1e3
   blob = g.serialize()
   print(f"    cold build      : {cold_ms:.1f} ms")
   print(f"    serialized plan : {len(blob)} bytes (cache this to disk / ship it)")
   t0 = time.perf_counter()
   g2 = cudnn.pygraph()
   try:
       g2.deserialize(HANDLE, blob)
   except TypeError:
       g2.deserialize(blob)
   warm_ms = (time.perf_counter() - t0) * 1e3
   print(f"    deserialize     : {warm_ms:.1f} ms  -> {cold_ms/max(warm_ms,1e-6):.1f}x faster startup")
   ws = torch.empty(max(g2.get_workspace_size(), 1), device=DEV, dtype=torch.uint8)
   g2.execute({UID_A: a, UID_B: bm, UID_C: out}, ws, handle=HANDLE)
   torch.cuda.synchronize()
   ref = torch.bmm(a.float(), bm.float())
   rel = ((out.float() - ref).abs().max() / ref.abs().max()).item()
   print(f"    rel err after reload: {rel:.2e}")
   return f"{len(blob)} B blob, reload {cold_ms/max(warm_ms,1e-6):.1f}x faster than rebuild"
serialization()

We then construct fused scaled dot-product attention with causal masking and validate it against torch.nn.functional.scaled_dot_product_attention. An SM80 check gates this entire section, since the fused kernels require Ampere or a newer architecture. To accommodate changes across the frontend’s 1.x releases, the causal argument includes fallbacks for the transition from use_causal_mask to diagonal_alignment and bound arguments.

Afterward, we serialize a built matmul graph into bytes, restore it in a new graph object, and run it using integer UIDs. Reloading the built graph avoids compilation costs entirely at process startup.

@section("7. Dynamic shapes with a shared kernel cache")
def dynamic_shapes():
   kc = cudnn.create_kernel_cache()
   def make(n):
       x = torch.randn(n, 64, 32, 32, device=DEV, dtype=DTYPE).to(memory_format=torch.channels_last)
       w = torch.randn(64, 64, 3, 3, device=DEV, dtype=DTYPE).to(memory_format=torch.channels_last)
       y = torch.empty(n, 64, 32, 32, device=DEV, dtype=DTYPE).to(memory_format=torch.channels_last)
       g = cudnn.pygraph(
           handle=HANDLE, name=f"dyn_{n}",
           io_data_type=TORCH2CUDNN[DTYPE],
           intermediate_data_type=cudnn.data_type.FLOAT,
           compute_data_type=cudnn.data_type.FLOAT,
           kernel_cache=kc,
           is_dynamic_shape_enabled=True,
       )
       X, Wt = tensor_of(g, x, "X"), tensor_of(g, w, "W")
       Y = g.conv_fprop(image=X, weight=Wt, padding=[1, 1], stride=[1, 1],
                        dilation=[1, 1], compute_data_type=cudnn.data_type.FLOAT)
       Y.set_output(True).set_data_type(TORCH2CUDNN[DTYPE])
       Y.set_dim(list(y.size())).set_stride(list(y.stride()))
       t0 = time.perf_counter()
       build(g)
       ms = (time.perf_counter() - t0) * 1e3
       ws = workspace_for(g)
       g.execute({X: x, Wt: w, Y: y}, ws)
       torch.cuda.synchronize()
       return ms
   times = [(n, make(n)) for n in (8, 16, 24, 32)]
   for n, ms in times:
       print(f"      batch {n:>3d}: build {ms:7.1f} ms")
   first, rest = times[0][1], [m for _, m in times[1:]]
   print(f"\n    first shape {first:.1f} ms, later shapes avg {sum(rest)/len(rest):.1f} ms")
   print("    The cache lets shape-variant graphs reuse an already-JIT'd kernel,")
   print("    which is what keeps variable batch/seqlen serving out of rebuild hell.")
   return f"first {first:.0f} ms vs subsequent {sum(rest)/len(rest):.0f} ms"
dynamic_shapes()
@section("8. CUDA Graph capture around a cuDNN execution plan")
def cuda_graph_capture():
   if not CONV_STATE:
       raise RuntimeError("section 2 did not run, nothing to capture")
   g, pack, ws = CONV_STATE["graph"], CONV_STATE["pack"], CONV_STATE["ws"]
   eager_ms = bench(lambda: g.execute(pack, ws))
   side = torch.cuda.Stream()
   side.wait_stream(torch.cuda.current_stream())
   with torch.cuda.stream(side):
       cudnn.set_stream(handle=HANDLE, stream=side.cuda_stream)
       for _ in range(3):
           g.execute(pack, ws, handle=HANDLE)
   torch.cuda.current_stream().wait_stream(side)
   torch.cuda.synchronize()
   cg = torch.cuda.CUDAGraph()
   with torch.cuda.graph(cg):
       cudnn.set_stream(handle=HANDLE, stream=torch.cuda.current_stream().cuda_stream)
       g.execute(pack, ws, handle=HANDLE)
   cudnn.set_stream(handle=HANDLE, stream=torch.cuda.current_stream().cuda_stream)
   replay_ms = bench(lambda: cg.replay())
   report("plain execute()", eager_ms)
   report("cuda graph replay()", replay_ms)
   print(f"    launch overhead removed: {(eager_ms-replay_ms)*1e3:.1f} us/iter")
   print("    Pointers are frozen at capture time -- reuse the same buffers and")
   print("    copy new data into them, or re-capture.")
   return f"{eager_ms:.3f} -> {replay_ms:.3f} ms via replay"
cuda_graph_capture()
banner("SUMMARY")
for name, res in RESULTS.items():
   print(f"  {name:<58s} {res}")
print("""
Where to go next
 - samples/python in the repo: FP8/MXFP8 attention, paged KV cache, MoE grouped GEMM
 - python/cudnn/: the open-sourced CuTe DSL kernels (SDPA, grouped GEMM + SwiGLU,
   block-sparse and native sparse attention) you can read and modify
 - debugging: CUDNN_FRONTEND_LOG_INFO=1 and CUDNN_FRONTEND_LOG_FILE=stdout
   (use level 10 during CUDA graph capture -- level 1 dumps tensors and is not
   capture-safe)
""")

The final experiments address two production considerations. First, four graphs with different batch sizes share a single kernel cache. By timing each build, we can observe subsequent shapes reusing a compiled kernel rather than incurring another JIT compilation cost.

Second, we place the convolution plan inside a CUDA graph. We assign the capture stream to the cuDNN handle so that its work is recorded in the graph, then measure how much per-iteration launch overhead disappears during replay.

Although the implementation is compact, it covers convolution, matmul, and attention kernels, all defined as graphs instead of individual library calls. That lower-level representation gives us control over which operations fuse into one kernel. Bias additions, activations, and AMAX reductions incorporated into epilogues therefore avoid writing intermediate results to memory.

It also lets us select execution engines directly. Benchmarking every candidate configuration quantifies the value of that choice instead of leaving it to a heuristic. Serialized plans and a kernel cache shared across shapes move compilation out of the hot path, while CUDA graph capture addresses repeated launch overhead.

Correctness checks against PyTorch are just as important as performance measurements. Cases where our implementation only matched PyTorch often reflected PyTorch already using cuDNN internally. Together, these results show where the graph API offers the most value: fusions unavailable at the framework level, frequently used shapes that warrant autotuning, and small kernels whose runtime is dominated by startup and launch costs.
